ABS ESD Filament - 1.75 mm - 0.5 kg

ABS ESD Filament - 1.75 mm - 0.5 kg

$28.00
Sale price  $28.00 Regular price  $69.00
ColorBlack

Fiberlogy ABS ESD is a specialized 3D printing filament designed to protect sensitive electronic components from electrostatic discharge (ESD). Thanks to its antistatic and dissipative properties, the material safely disperses charge energy which significantly reduces the risk of electronic damage and prevents unexpected device failures. Electrostatic discharges can cause serious equipment malfunctions and expensive repairs. By using ABS ESD, engineers and manufacturers can minimize ESD-related risks already at the stage of designing and producing functional parts.

Properties:

  • high resistance to electrostatic discharge and chemicals,
  • high impact strength,
  • resistance to high temperatures and scratches,
  • suitable for mechanical and chemical post-processing.

Fiberlogy ABS ESD is an ideal material for advanced electronic, measurement and industrial applications. It is perfect for printing:

  • enclosures and covers for integrated circuits and PCB boards,
  • protective components for sensors, connectors and electronic modules,
  • housings for measuring and testing equipment,
  • parts requiring durable protection against electrostatic discharge.

Print settings

  • Printing temperature250-265°C
  • Bed temperature90-110°C
  • Build surfaceSmooth PEI + adhesive, Textured PEI, Glass + adhesive
  • Drying conditions60°C / 4h
  • Enclosurerecommended
  • Cooling fan0-10%

Tips and recommendations

  • Nanoparticles:Due to the presence of nanoparticles, the filament structure is not smooth. Occasional thickening is natural but does not affect the correct filament diameter, which remains within the declared tolerance.
  • Recommended 0.6 mm nozzle:To avoid potential clogging with wood particles, we recommend cleaning the extruder after each FiberWood print using any PLA filament. Minimum recommended nozzle diameter – 0.5 mm.

Properties

  • Density1.05 g/cm³
  • Tensile Strength @ Break55 MPa (ISO 527)
  • Tensile Modulus2100 MPa (ISO 527)
  • Elongation @ Break5% (ISO 527)
  • Izod Impact Strength (Notched) @ 23℃5 kJ/m2 (ISO180)
  • Surface Resistivity3,8x10⁷ – 8,1x10⁷ Ω (ASTM D257 1991)
  • Volume Resistivity4,1x10⁷ Ω*cm (IEC 60093)
